IR2110PBF High/Low Side Driver with 600V Rating 2.5A Peak Output 10V-20V Supply 120ns Switching UVLO Protection & Compact PDIP Package

IR2110PBF High/Low Side Driver with 600V Rating 2.5A Peak Output 10V-20V Supply 120ns Switching UVLO Protection & Compact PDIP Package

Features

• Floating channel designed for bootstrap operation Fully operational to +500V or +600V Tolerant to negative transient voltage dV/dt immune

• Gate drive supply range from 10 to 20V

• Undervoltage lockout for both channels

• 3.3V logic compatible Separate logic supply range from 3.3V to 20V Logic and power ground ±5V offset

• CMOS Schmitt-triggered inputs with pull-down

• Cycle by cycle edge-triggered shutdown logic

• Matched propagation delay for both channels

• Outputs in phase with inputs

Applications

Motor Drive Systems

Brushless DC (BLDC) motor drives

Industrial servo motor controllers

Power tool motor drive circuits

Power Conversion Systems

DC-AC inverters (solar/UPS applications)

High-frequency switch-mode power supplies (SMPS)

Class D audio power amplifiers

Industrial Power Electronics

Variable frequency drive circuits

Welding machine power modules

Induction heating equipment

New Energy Applications

Photovoltaic inverter gate drives

EV charging stations

Wind power converters

Description

The IR2110/IR2113 are high voltage, high speed power MOSFET and IGBT drivers with independent high and low side referenced output chan nels. Proprietary HVIC and latch immune CMOS technologies enable ruggedized monolithic construction. Logic inputs are compatible with standard CMOS or LSTTL output, down to 3.3V logic. The output drivers feature a high pulse current buffer stage designed for minimum driver cross-conduction. Propagation delays are matched to simplify use in high frequency applications. The floating channel can be used to drive an N-channel power MOSFET or IGBT in the high side configuration which operates up to 500 or 600 volts.
