BSM50GD120DN2E3226 1200V/50A IGBT Module Dual Configuration Low VCE(sat) High Speed Switching Low Loss Built-in NTC Isolated Baseplate Industrial Grade for Motor Drives & Solar Inverters

BSM50GD120DN2E3226 1200V/50A IGBT Module Dual Configuration Low VCE(sat) High Speed Switching Low Loss Built-in NTC Isolated Baseplate Industrial Grade for Motor Drives & Solar Inverters

Features

• Voltage/Current Rating: 1200 V / 50 A

• Configuration: Dual IGBT

• Low Saturation Voltage: VCE(sat) for reduced conduction losses.

• Low Switching Losses: Optimized for high-frequency operation.

• Built-in NTC Thermistor: Enables thermal protection and monitoring.

• Isolated Baseplate: Facilitates easy heatsink mounting and improves safety.

• High Reliability: Industrial-grade longevity and robustness.

• Low Thermal Impedance: Efficient heat dissipation.

Applications

• Solar Inverters: Used in the power conversion stage of residential and commercial photovoltaic systems.

• Uninterruptible Power Supplies (UPS): Employed in the inverter section of online and line-interactive UPS systems.

• Industrial Motor Drives: For controlling AC motors in pumps, fans, and compressors.

• Welding Equipment: Provides the switching core for industrial welding machines.

• Induction Heating: Used in the power circuits of induction heating and melting systems.

Description

The BSM50GD120DN2E3226 is a high-power dual IGBT module designed for robust performance in demanding energy conversion applications. It is rated for 1200V and 50A, offering a reliable power stage for medium to high-power systems. The module is engineered for high efficiency, featuring a low collector-emitter saturation voltage (VCE(sat)) and optimized for low switching losses.

This module includes critical built-in features such as an NTC thermistor for precise temperature monitoring and an isolated baseplate for simplified and safe thermal management. Its industrial-grade construction ensures high reliability and long-term stability under rigorous operating conditions, making it a cornerstone for durable power electronic designs.
